Layers

The first column of the Options modal contains checkboxes for a number of different data layers:

  • Country Shading: Highlights political borders and shades each country in a different color.
  • Terminator: Shows a visual of the day/night terminator to indicate where the grayline is. Updates every 15 seconds.
  • Maidenhead Gridsquares: When zoomed out, shows the 4-digit maidenhead gridsquares. When zoomed in, shows 6-digit grids.
  • CQ Zones: Shows borders of, and labels CQ zones, if you're a zone hunter type. There's a few glitches with this layer currently.
  • ITU Zones: Shows borders of, and labels ITU zones, if you're a zone hunter type. There's a few glitches with this layer currently.
  • DXCC: Highlights the borders of, and labels each DXCC entity.
  • Timezones: Shows borders of, and labels world timezones.
  • MUF Contours: Shows contour lines and colored shading to illustrate the Maximum Usable Frequency (MUF). Updates every 5 minutes based on data up to 15 minutes old.
  • FOF2 Contours: Shows contour lines and colored shading to illustrate the Critical Frequency (FOF2). Updates every 5 minutes based on data up to 15 minutes old.

Spotting

The middle column of the Options modal contains checkboxes for each of the main HF amateur bands. You can enable these individually or any combination of them to view recent spots on that band from PSK Reporter. This can give a real-time view of propagaion on a given band! Spotting data is refreshed on my server every 5 minutes, and the map should pick up the new data within a minute of the server refreshing. Down the road, more features will be added here, like seeing spots of your callsign, etc

Widgets

The first column of the Options modal contains checkboxes for a number of different data layers:

  • UTC Clock: Shows a realtime UTC clock at the bottom of the map.
  • Callsign Lookup: Adds an input box at the top of the map where callsigns can be entered to see information about them.
  • SWPC Snapshot: Adds a table on the left side of the map containing a snapshot of current space weather conditions. Data updated every 15 minutes.
  • SDO Imagery: Adds an image carousel to the right side of the map containing current SDO imagery of the sun.
  • Aurora Forecast: Adds images to the right side of the map containing the current Aurora Forecast maps from NOAA.
